| Item |
|
Units |
Specifications |
Conditions |
| 1 |
Rated Voltage |
VDC |
12 |
|
| 2 |
Operating Voltage |
VDC |
3 ~ 20 |
|
| 3 |
Rated Current |
mA(Max) |
20 |
At 12VDC / 3.5KHz |
| 4 |
Sound Output At 10 cm |
dBA(Min) |
88 |
At 12VDC / 3.5KHz |
| 5 |
Resonant Frequency |
Hz |
3500±500 |
|
| 6 |
Operating Temp. |
℃ |
-20 ~ +70 |
|
| 7 |
Storage Temp. |
℃ |
-30 ~ +80 |
|
| 8 |
Weight |
g |
5 |
|
