| Items |
|
Units |
Specifications |
Conditions |
| 1 |
Rated Voltage |
VDC |
12 |
|
| 2 |
Operating Voltage |
VDC |
3-20 |
|
| 3 |
Rated Current |
mA(Max) |
10 |
At 12 VDC |
| 4 |
Sound Output At 10cm |
dBA(Min) |
95 |
At 12VDC |
| 5 |
Resonant Frequency |
Hz |
3400±500 |
|
| 6 |
Operating Temp. |
℃ |
-20 ~ +80 |
|
| 7 |
Storage Temp. |
℃ |
-30 ~ +90 |
|
| 8 |
Tone Nature |
|
Single |
|
| 9 |
Weight |
g |
4 |
|
