| Items |
|
Units |
Specifications |
Conditions |
| 1 |
Rated Voltage |
VDC |
12 |
|
| 2 |
Operating Voltage |
VDC |
4.0 ~ 14.0 |
|
| 3 |
Rated Current |
mA(Max) |
15 |
At 12VDC |
| 4 |
Sound Output |
dBA(Min) |
88 |
At 12DC / 30cm |
| 5 |
Resonant Frequency |
Hz |
3500 ± 500 |
|
| 6 |
Tone Nature |
FAST PULSE 3.0 ± 30% Hz |
|
|
| 7 |
Operating Temp. |
℃ |
-20 ~ +60 |
|
| 8 |
Storage Temp. |
℃ |
-30 ~ +70 |
|
| 9 |
Weight |
g |
15 ± 1.0 |
|
A &
