| Items |
|
Units |
Specifications |
Conditions |
| 1 |
Rated Voltage |
VDC |
12 |
|
| 2 |
Operating Voltage |
VDC |
3 ~ 28 |
|
| 3 |
Rated Current (Max) |
mA |
15 |
At 12 VDC |
| 4 |
Min Sound Output |
dBA |
90 |
At 12 VDC / 30cm |
| 5 |
Resonant Frequency |
Hz |
3500±500 |
|
| 6 |
Tone Nature |
Fast pulse |
|
|
| 7 |
Operating Temp. |
℃ |
-30 ~ +75 |
|
| 8 |
Storage Temp. |
℃ |
-40 ~ +85 |
|
| 9 |
Weight |
g |
4 |
|
