| Items |
|
Units |
Specifications |
Conditions |
| 1 |
Rated Voltage |
VDC |
12 |
|
| 2 |
Operating Voltage |
VDC |
4~28 |
|
| 3 |
Rated Current |
mA(Max) |
8 |
At 12 VDC |
| 4 |
Sound Output At 30 cm |
dBA(Min) |
78 |
At 12 VDC |
| 5 |
Resonant Frequency |
Hz |
2900±500 |
|
| 6 |
Tone Nature |
SLOW PULSE (1.2Hz) |
|
|
| 7 |
Operating Temp. |
℃ |
-30 ~ +85 |
|
| 8 |
Storage Temp. |
℃ |
-40 ~ +85 |
|
| 9 |
Weight |
g |
32 |
|
