| Items |
|
Units |
Specifications |
Conditions |
| 1 |
Rated Voltage |
VDC |
12 |
|
| 2 |
Operating Voltage |
VDC |
3~20 |
|
| 3 |
Rated Current |
mA(Max) |
60 |
At 12VDC |
| 4 |
Sound Output At 10cm |
dBA(Min) |
105 |
At 12VDC |
| 5 |
Resonant Frequency |
Hz |
2900±500 |
|
| 6 |
Tone Nature |
Single |
|
|
| 7 |
Operating Temp. |
℃ |
- 20 ~ +60 |
|
| 8 |
Storage Temp. |
℃ |
- 30~ +70 |
|
| 9 |
Weight |
g |
43 |
|
